96-Well Deep Well Plates
Options:
0.36mL 96-Well Deep Well Plate, V-Bottom, round well, non-sterile
0.5mL 96-Well Deep Well Plate, V-bottom, round well, non-sterile
0.5mL 96-Well Deep Well Plate, V-bottom, round well, sterile
1.0mL 96-Well Deep Well Plate, U-bottom, round well, non-sterile
Length and width of the deep well plate comply with the SBS international standards
Depth of wells is increased based on the appearance and size of normal plates (mainly 96-well and 384-well plates) to enlarge the volume of each well
Manufacturing material (currently mostly used is polypropylene (PP)) is changed and surface treatment process has been improved for this series of deep well plates to adapt to its specific use range
Deep well plates of NEST have a variety of specifications, conforming with the needs of fully automatic workstations and experiments
1. Sample storage: can replace the conventional 1.5mL centrifuge tube to store samples, can be arranged tidily to save space, with large storage capacity, and can withstand the -80℃ refrigerator condition. Therefore, it’s also called storage plate.
2. Sample processing: can be used in combination with multi-pass pipettes, high-throughput automatic liquid processors and respective software to allow the high-throughput operation of biological samples (ex. protein precipitation, liquid extraction, nucleic acid extraction, etc). Greatly improve the efficiency of sample processing. Can withstand high temperature and high-pressure sterilization at 121℃.
3. Sample injection: suitable for the automatic devices of various companies, it can be directly placed in the sample compartment of the automatic device for injection. Compared to conventional sample injection, it can not only double the sample amount placed in the sample compartment, but also recognizes the direct sample injection of samples after processing on the 96-well plate, eliminating the tedious work of pipetting and placing samples back and forth.
Application
Genomic DNA extraction, plasmid DNA extraction, and nucleic acid extraction and purification of various samples
High-throughput automatic liquid operation to achieve high-throughput operations, such as protein precipitation, liquid extraction, and processing of animal tissues, bacteria, plants, soil, clinical samples, yeasts, etc
Material
USP VI polypropylene material
High chemical stability
Features
Temperature range: -80°C to 120°C
Autoclavable
Centrifugal strength up to 3000g
Compatible with multi-channel pipette and automatic equipment
Optimized bottom design to minimize residual volume
Clear alphanumeric codes for easy identification
Conform to SBS/ ANSI
Specific 96-well deep plate used in nucleic acid extraction
Stackable, reliable tight sealing
Non-pyrogenic, DNase/RNase free
Internal Reference:
500101
